Fairbanks Series III Bench Scales - Manual (Page 15)

50778 15 07/10 -- Rev. 6
A. Specifications
Baud rate: 2400 / 9600
Parity: None
Data Bits: 8
Stop Bits: 1
B. Data Format
NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
G R SP x x x x x x x SP l/k b/g CR LF
N T SP x x x x x x x SP l/k b/g CR LF
T A SP x x x x x x x SP l/k b/g CR LF
Q T Y SP x x x x x x SP P C S CR LF
A P W 1 0 0 0 SP x x x x x x SP l/k b/g CR LF x
CR LF
CR LF
CR LF
CR LF
CR LF
Footnote(s): Characters designated by an “X” are characters 0~9
Leading Zeros are replaced with spaces “SP”.
C. Connections
DB-9 Male
Pin Description
2 TX
5 GND
Appendix
I: RS232 Specifications
