07/13 16 51245 Rev. 3
Section 8: Parts - 18” x 24” Platforms
18” x 24” Platform (50 lb., 100 lb., and 300 lb. capacities)
Item Part no. Description
2 15835 Load cell - 150 kg – for platforms 24770, 24771 & 24772
2 21350 Load cell (hermetically sealed) - 100 kg – for platforms 24862, 24863 & 24864)
4 14219 Foot assembly (used as a bumper)
5 24430 Spider, platform
6 24429 Cover, platform
9 15831 Spacer, load cell (.250 thick)
10 24428 Base, platform
11 24406 Clip, ground
13 11050 Screw, machine, hex head cap, 5 /
16
- 18 x 1.00
18 11920 Adhesive, screw
19 17613 Tie wire
20 14220 Foot assembly
24 22963 Nut, nylon, stop
34 11039 Bull’s eye level
35 13223 Adhesive sealant
Diagram on next page.
