07/13 14 51245 Rev. 3
Section 7: Parts - 18” x 18” Platforms
18” x 18” Platform (50 lb., 100 lb., 150 lb., and 300 lb. capacities)
Item Part No. Description
2 14965 Load cell – 100 kg – for platforms 24766, 24767 and 24768
2 14966 Load cell – 150 kg – for platform 24769
4 14219 Foot assembly (used as a bumper)
5 23538 Spider, platform
6 23548 Cover, platform
8 24843 Shim, load cell (.750 thick) for platform 24769
9 24781 Shim, load cell (.500 thick)
10 23547 Base, platform
11 24406 Clip, ground
12 24844 Screw, machine, hex head cap, ⅜ – 16 x 1.50 for platform 24769
13 11047 Screw, machine, hex head cap, ⅜ – 16 x 1.25
16 24782 Screw, set, socket head, cup point, ¼ – 20 x .88
17 11131 Nut, hex, jam, ¼ – 20
18 11920 Adhesive, screw
19 17613 Tie wire
20 14220 Foot assembly
24 22963 Nut, nylon, stop
34 11039 Bull’s eye level
35 13223 Adhesive sealant
Diagram on next page.
