07/13 12 51245 Rev. 3
Section 6: Parts - 12” x 12” Platforms
12” x 12” Platform (30 lb, 50 lb, and 100 lb capacities)
Item Part No. Description
2 14963 Load cell – 30 kg – for platform 24763, 24764, 24765
2 14964 Load cell – 60 kg – for platform 26029.
4 14219 Foot assembly (used as a bumper)
5 23971 Spider, platform
6 23977 Cover, platform
7 24780 Shim, load cell (.185 thick)
10 23976 Base, platform
11 24406 Clip, ground
13 11051 Screw, machine, hex head cap, .23 – 20 x .75
16 24408 Screw, set, socket head, cup point, 10 – 32 x .50
17 11103 Nut, hex, 10 – 32
18 11920 Adhesive, screw
19 17613 Tie wire
20 14220 Foot assembly (used as a bumper)
21 11039 Bull’s eye level
22 13223 Adhesive sealant
24 22963 Nut, nylon, stop
Diagram on next page.
