07/13 10 51245 Rev. 3
Section 5: Parts - 10” x 10” Platforms
10” X 10” Platform (2 lb., 6 lb., and 25 lb. capacities)
Item Part No. Description
2 14961 Load cell – 7 kg – for platforms 24760, 24761, and 24762
2 14963 Load cell – 30 kg – for platform 24763
4 14219 Foot assembly (used as a bumper)
5 23664 Spider, platform
6 23669 Cover, platform
7 24779 Shim, load cell (.109 thick)
10 23668 Base, platform
11 24406 Clip, ground
13 11051 Screw, machine, hex head cap, .23 – 20 x .75
16 24408 Screw, set, socket head, cup point, 10 – 32 x .50
17 11103 Nut, hex, 10 – 32
18 11920 Adhesive, screw
19 17613 Tie wire
20 14220 Foot assembly
21 11039 Bull’s eye level
22 13223 Adhesive sealant
24 22963 Nut, nylon, stop
Diagram on next page.
