2. Insert the vertical support rods into the left and right sleeves of the screen material.
3. Place the screen material (Elite Screens logo facing up) inside the metal frame.
4. Attach the screen material by the exposed areas of the vertical and horizontal support rods onto the metal
frame using the Velcro and Button bands as shown below.
Vertical support rod
Front of Screen material
1. Begin by attaching
the top frame with the
button bands (L)
2. Next, attach the
bottom frame with the
long velcro bands (J)
3. Finally, attach the left
and right frame with the
long velcro bands (K
)
Vertical support rod
Note: Attach the bands
on the left and right
sides as tightly as
possible. This will
provide the tension
required to make the
screen material flat
