Power cable – Elite Screens Evanesce Tension (EU) User Manual
Page 8
7
6. Install plastic cover panel (I) to complete the installation.
Power Cable
1.
The Evanesce Tension series screen includes a power cord for using in a non-concealed power outlet.
If your installation however will be entirely concealed including the power outlet, we strongly
recommend a hardwire connection. Please refer to the diagram below for wiring information for both
110v and 220v variants.
Yellow/Green
(Ground)
Blue (Common)
Gray (Hot)
