3.
The expanding bolts (A) mount into thick wood beams, stone or concrete and will support the
screen. Use the Socket wrench (G) to attach the hexagonal screws (D). The expanding bolts should be
firmly tightened and tested to make sure that they will hold the weight of the screen.
5. Push the screen up into the space. Use the threaded rods (B) to attach the screen assembly to the
ceiling. The hexagonal screws (D) will connect the screen to the rest of the assembly. Once firmly in
place, use the nuts (C) to ensure a firm connection. Use the socket wrench (H) to make sure that the bolts
are firmly tightened.
Ceiling
Socket wrench (H)
Push
