Evanesce tension series dimensions table, Unit: mm – Elite Screens Evanesce Tension (U.S) User Manual
Page 11

11
Rev.122411-AS
www.elitescreens.com
Unit: mm
Model
Nominal
Diagonal
View
Width
(A)
(A1)
Case
Length
(A2)
(A3)
(A4)
(A5)
View
Height
(B)
Top
Border
(B1)
(B2)
Case H
(B3)
Overall
Height
(B4)
(B5)
Case
Width
(C)
C1
C2
C3
C4
C5
C6
ITE100VW2-E8
100"(4:3)
2032
95
2347 2407
1947
2342
1524
203
1827
118
1945
100
98
50
925
145
180 1145-1205
148
ITE120VW2-E8
120"(4:3)
2438
95
2770 2830
2370
2765
1828
203
2131
118
2249
100
98
50
925
145
180 1145-1205
148
ITE100HW2-E8
100"(16:9)
2214
95
2530 2590
2130
2525
1245
203
1548
118
1666
100
98
50
925
145
180 1145-1205
148
ITE106HW2-E8
106"(16:9)
2347
95
2660 2720
2260
2655
1320
203
1623
118
1741
100
98
50
925
145
180 1145-1205
148
ITE120HW2-E8
120"(16:9)
2657
95
2972 3032
2572
2967
1494
203
1797
118
1915
100
98
50
925
145
180 1145-1205
148
ITE135HW2-E8
135"(16:9)
2989
95
3310 3370
2910
3305
1681
203
1984
118
2102
100
98
50
925
145
180 1145-1205
148
ITE114XW2-E8
114"(16:10)
2455
95
2770 2830
2370
2765
1534
203
1837
118
1955
100
98
50
925
145
180 1145-1205
148
ITE126XW2-E8
126"(16:10)
2714
95
3030 3090
2630
3025
1696
203
1999
118
2117
100
98
50
925
145
180 1145-1205
148
Unit: inch
Model
Nominal
Diagonal
View
Width
(A)
(A1)
Case
Length
(A2)
(A3)
(A4)
(A5)
View
Height
(B)
Top
Border
(B1)
(B2)
Case H
(B3)
Overall
Height
(B4)
(B5)
Case
Width
(C)
C1
C2
C3
C4
C5
C6
ITE100VW2-E8
100"(4:3)
80.0
3.7
92.4
94.8
76.7
92.2
60.0
8.0
71.9
4.6
76.6
3.9
3.9
2.0
36.4
5.7
7.1 45.1-47.4
5.8
ITE120VW2-E8
120"(4:3)
96.0
3.7
109.1 111.4
93.3 108.9
72.0
8.0
83.9
4.6
88.5
3.9
3.9
2.0
36.4
5.7
7.1 45.1-47.4
5.8
ITE100HW2-E8
100"(16:9)
87.2
3.7
99.6 102.0
83.9
99.4
49.0
8.0
60.9
4.6
65.6
3.9
3.9
2.0
36.4
5.7
7.1 45.1-47.4
5.8
ITE106HW2-E8
106"(16:9)
92.4
3.7
104.7 107.1
89.0 104.5
52.0
8.0
63.9
4.6
68.5
3.9
3.9
2.0
36.4
5.7
7.1 45.1-47.4
5.8
ITE120HW2-E8
120"(16:9)
104.6
3.7
117.0 119.4 101.3 116.8
58.8
8.0
70.7
4.6
75.4
3.9
3.9
2.0
36.4
5.7
7.1 45.1-47.4
5.8
ITE135HW2-E8
135"(16:9)
117.7
3.7
130.3 132.7 114.6 130.1
66.2
8.0
78.1
4.6
82.8
3.9
3.9
2.0
36.4
5.7
7.1 45.1-47.4
5.8
ITE114XW2-E8
114"(16:10)
96.7
3.7
109.1 111.4
93.3 108.9
60.4
8.0
72.3
4.6
77.0
3.9
3.9
2.0
36.4
5.7
7.1 45.1-47.4
5.8
Evanesce Tension Series Dimensions Table
The listed measurements are for general reference only. Please contact Elite Screens to verify product design and dimensions before attempting to integrate its products with
any structural or furniture modification. Although a manufacturer may offer product advice, it may be taken or disregarded at the integrator’s discretion. Elite Screens will not be
held responsible or be otherwise liable for faulty installations. Note Data error +/- 1”
