Total Hydrocarbon Analyzer Operational Theory
2-5 Teledyne Analytical Instruments
chamber against excessive temperature, which may occur if the tempera-
ture controlling system fails.
2.1.8 Output
The electrometer-amplifier output is connected to a span potentiom-
eter, whose slider is connected to a 3½ digit digital panel meter (DPM) a
voltage-to-current (E-to-I) converter, as well as optional output circuits
which may be utilized, such as alarm comparators. Description of optional
circuits employed can be found in the Printed Circuit Board Description
section of Chapter 5.
