Teledyne 3110 – Portable Trace/Percent Oxygen Analyzer, unapproved version - Manual (Page 6)

Model 3110
vi Teledyne Analytical Instruments
Table of Contents
List of Figures............................................................................ viii
Introduction ................................................................................ 10
1.1 Introduction 10
1.2 Features 11
1.3 Method of Analysis 13
1.4 Micro-Fuel Cell 13
1.4.1 Cell Warranty 13
1.5 Accuracy and Response 14
1.6 Signal Output 14
1.7 Compact Packaging 14
Installation .................................................................................. 17
2.1 Charging the Batteries 17
2.2 Gas Connections 18
2.3 Sensor Installation 20
2.3.1 Installing a Trace Sensor 20
2.4 Calibration 21
2.4.1 Calibration Procedure for Trace Analysis 21
2.4.2 Bleeding the Regulator and Purging the Gas Line 22
2.5 Set the Sample Flow rate 22
2.6 External Signal 23
Operation .................................................................................... 24
3.1 Front Panel Interface 24
3.1.1 ENTER Key 24
3.1.2 ESCAPE Key 25
3.1.3 UP/DOWN Keys 25
3.2 Operation and Setup Screens and Menus 26
3.2.1 POWER ON Screen 27
3.2.2 HOME Screen 27
