Appendix Model 3110
48 Teledyne Analytical Instruments
Appendix
A.1 Specifications
TAI Sales Order Number:
Instrument Serial Number:
Micro-fuel Cell Class: B-2, A-2C, B-2CXL, Insta Trans
Ranges of Analysis: 2 user defined ranges*
Accuracy: ±2% of scale or ±1 PPM (whichever is
greater) at constant temperature;
±5% of reading or ±1 PPM (whichever is
greater) over the operating temperature
range.
Operating Temp. Range: 0 °C to 40 °C (32 °F to 104 °F)
Sample Temp. Range: 0-40°C
Sample Flow rate: 0.5 – 2.5 SCFH
Recommended Span Gas: 80-90% of range most likely to be used
Signal Output: 0-1VDC
Dimensions: 10.9” x 6.2” x 5.2” deep
Weight: 4.38 lbs. (1.99kg.)
Power Requirements: 100-240 VAC 47-63H Charging Adapter
* In auto range mode only
