Operators Instructions for
HYDRAFLOW S4VHL Hydraulic Submersible Pump
Manual No/Rev
W79-003E / 4
Our policy is one of continuous improvement and we reserve the right to alter specifications at any time
Page 11 of
12
8.2 Parts List
Always mention serial # when ordering parts
Item
Part #
Description
1.
HT9300313
HT9300146
Pigtail Hose Assembly 1" x 3/4”
Pigtail Hose Assembly 1"
2.
--------
(Not used on this model)
3.
HT9300290
Lifting Bracket
4.
HT0000153
Lock Washer, 1/2", stainless (2 req.)
5.
HT9300412
Hydraulic motor
6.
19394/M
Quick Release Flat Face Hydraulic Connector: 1"NPT Male
7.
19394/F
Quick Release Flat Face Hydraulic Connector: 1"NPT Female
8.
---------
(Not used on this model)
9.
HT0000154
Hex Bolt, 1/2" x 1", stainless (4 req.)
10.
HT0700156
O Ring
11.
HT0100157
Snap-ring
12.
HT9300158
Bearing, upper
13.
HT9300159
Shaft
14.
HT9300158
Bearing, lower
15.
HT0200161
Hex Plug
16.
---------
(Not used on this model)
17.
---------
(Not used on this model)
18.
---------
(Not used on this model)
19.
HT0009119
Hex Bolt, 1/2" x 1-1/2", stainless (8 req.)
20.
HT0000166
Hex Bolt, 1/2" x 3/4", stainless (3 req.)
20a.
HT9300287
Vent Bolt , stainless
21.
HT0600153
Lock Washer, 1/2", stainless (4 req.)
22.
HT9300151
HT9300227
Bearing housing (Aluminium)
Bearing housing (Ductile Iron)
23.
HT9300167
Wear plate
24.
HT0700168
O Ring
25.
HT9300169
HT9303169
Seal Assembly (Standard Carbon/Ceramic)
Seal Assembly (Optional Silicon Carbide)
26.
HT9300160
Impeller
27.
HT9300171
Wear ring
28.
HT0700168
O Ring
29.
HT9300173
Cone Washer
30.
HT0000174
Socket head bolt, 1/2" x 1-1/4", stainless
31.
HT0003508
Hex Head Bolt (1/2" x 2" SS) (4 req.)
32.
HT0000153
Lock Washer, 1/2", stainless (4 req.)
33.
HT9300310A
HT9300310
Discharge Adaptor 4" NPT(F) aluminium
Discharge Adaptor 4" NPT(F) ductile Iron
34.
HT9300314
O Ring (for 0310 )
35.
HT9300308A
Volute (Aluminium)
HT9300308
Volute (Ductile Iron)
36.
HT9300294
Strainer Base
37.
HT0000176
Lock Washer, 5/8", stainless (4 req.)
38.
HT0000179
Hex Bolt, 5/8 x 1", stainless (4 req.)
Part Not Illustrated
19428
Bauer 4"Male/4NPT Male
