Server PUMPS User Manual
Server Kitchen
PUMP MANUAL 01662-REVB-102813
GAGING COLLARS (Portion Control)
KNOBS
LOCKING COLLAR
HEAD TUBES
HEAD INSERT
SPRINGS
WASHER
PISTONS
SEAL ASSEMBLY
SEAL
SEAL O-RING
LIDS
CYLINDERS
VALVE BODIES
DISCHARGE TUBES
DISCHARGE
TUBE NUT
DISCHARGE TUBE O-RING (1” D)
Smaller gaging collar added
will reduce portion served
by .25 oz, larger by .50 oz
SILICONE GASKET
Go to server-products.com for parts breakdowns and translations
PARTS INCLUDED VARY DEPENDING ON PUMP
