6. DISPLAY MODE
You can display the HDD information as shown on Figure 6A below at any time by pressing the
Display button. The unit displays status on a monitor as shown next.
Figure 6A
HDD MODEL: Shows the models of HDD.
PICTURE 08/23/2006 10:05:24
HDD SIZE: The capacity of the installed hard disks.
HDD U
HDD1 HDD2
SED: Percentages of system recording.
HDD MODEL ST340015A
HDD SIZE 40G HDD READ: Percentages of the recorded file for
reading.
HDD USED 61%
HDD READ 00% NO DETECT
HDD STATUS REC
HDD STATUS: Indicates the device status.
REC LIST 005
ALM LIST 0000
• REC: The device is in the recording mode.
HDD REST/TOTAL TIME
14/ 24 hr • PLAY: The device is in the playback mode.
USB REST/TOTAL SIZE 620/ 978 MB
• REC+PLAY : The device is in the recording and
playback mode.
REC LIST: The numbers of the recording lists.
ALM LIST: The numbers of the alarm-recording lists.
HDD REST/TOTAL TIME:
Total 14 hours remaining time available.
Total 24 hours recording time available.
USB REST/TOTAL TIME:
Total 620 MB rest capacity of memory available.
Total 978 MB memory capacity available.
Press the Display button again; the unit will display the information as shown in Figure 6B below.
Figure 6B
RECORD MODE: Shows the mode of recording.
STOP; MANUAL; TIMER; ALARM.
PICTURE 08/23/2006 10:05:26
RECORD MODE STOP
RECORD RATE: Shows the rate of recording.
RECORD RATE 60 F/S
RECORD QUALITY STANDARD RECORD QUALITY: Shows the quality of recording.
RESOLUTION 720 X 240
RESOLUTION: Shows the resolution of recording. DISK FULL STOP
DISK FULL: Shows the way to utilize storage media
in case of a full disk.
MAC ADDRESS : 0A:0B:0C:0D:0E:0E
IP ADDRESS : 192.168.001.224
SUBNET MASK : 255.255.254.000
GATEWAY : 192.168.001.254
MAC ADDRESS: Network MAC address.
IP ADDRESS: Network IP address.
SUBNET MASK: Network mask.
GATEWAY: Network gateway.
Press any button (except the ^, v, <, > buttons) to escape the Display mode.
29
