PARTS
Item Quantity Part Number Description
A 1 0525-0085 Lip, Cylinder
B
1 0525-0066 Hoist Cylinder 10” and 12” Pits
1 0525-0104 Hoist Cylinder 15” Pits
C 1
9394-0024 Reservoir Short (5’-6’ Lg) Includes Hoses 9904-0102 & 9904-0103
9394-0053 Reservoir Long (8’ Lg) Includes Hoses 9904-0102 & 9904-0103
D 1 9301-0199 Breather, Reservoir
E 4 21010011 Hex Head Capscrew
F 4 2101-0058 Lock Washer
G 4 2101-0060 Flate Washer
H
1 9394-0014 Motor Assembly 115V 1 Ph
1 9394-0015 Motor Assembly 460V 3 Ph
1 9394-0033 Motor Assembly 208V 1 Ph
1 9394-0034 Motor Assembly 230V 1 Ph
1 9394-0035 Motor Assembly 575V 3 Ph
1 9394-0043 Motor Assembly 208V 3 Ph
1 9394-0044 Motor Assembly 230V 3 Ph
I 1 9301-0132 Pump 1.75Gpm
J - - Left Blank
K 6 2101-0089 Cap Screw, 3/8-16 UNC x 2.0 in.
L 1 9904-0090 Hose, 17.50” Lg, #8 Jic Swivel Both Ends (5’-6’ LG)
M
1 9904-0059 Hose, 35.00” Lg, #6 Jic Swivel Both Ends (8’ LG)
1 9904-0137 Hose, 60.00” Lg, #6 Jic Swivel Both Ends
N 1 9904-0103 Hose, 10.50” Lg, #8 ORB to #8 Jic Swivel
O 1 9904-0059 Hose, 35.00” Lg, #6 Jic Swivel Both Ends
P 1 9904-0083 Hose, 44.50” Lg, #6 Jic Swivel Both Ends
Q 2 9904-0102 Hose, 21.00” Lg, #8 ORB to #8 Jic Swivel
R 1 9301-0115 Fitting 90 Deg #6 ORB To #8 Jic
S 1 9301-0116 Fitting 90 Deg #8 ORB To #8 Jic
T 1 8583-0089 Vertical Valve Assembly
1 Provide dock leveler serial number, platform size, and lip size when calling or faxing orders .
2 Provide length and width of inspection plate opening when calling or faxing orders .
SC Vertical Leveler Hydraulic Components
4111-0008 — April 2008 37
