INTRODUCTION
General Information
AP-Series dock levelers are available in the following
sizes, weight capacities, and options:
Width: AP
6 ft (1828.8 mm)
6-1/2 ft (1981.2 mm)
7 ft (2133.6 mm)
Length
6 ft (1828.8 mm)
8 ft (2438 mm)
10 ft (3048 mm)
Capacity (CIR*)
20,000 lb (44 092 kg)
25,000 lb (11 340 kg)
30,000 lb (13 608 kg)
35,000 lb (15 876 kg)
40,000 lb (18 144 kg)
45,000 lb (20 412 kg)
50,000 lb (22 680 kg)
* CIR (Comparative Industry Rating)
All docks are available in 115V motors only.
The AP dock leveler comes equipped with an
electrical control panel, which allows push button
operation of the dock leveler functions. Each AP dock
leveler unit and control panel has been factory
prewired and tested to ensure satisfactory operation.
To illustrate which connections are to be made in the
field at installation, electrical drawings are included
with each order or by contacting Poweramp Technical
Services.
Once again, thank you and congratulations on your
purchase of a Poweramp AP dock leveler.
Dock Leveler Stock Specifications
Congratulations on your choice of a Poweramp dock
leveler. This manual covers the Air Bag, AP model air
powered dock leveler.
Designed by Poweramp to be a marvel of simplicity
and efficiency, your dock leveler, when properly
installed, will provide many years of trouble-free
performance with an absolute minimum of
maintenance. Its revolutionary air bag system
efficiently controls and operates every function. To
obtain maximum performance and longest possible
use, a simple program of preventive maintenance is
recommended.
