Poweramp AP SERIES AIR POWERED 4.2009 - Manual (Page 22)

20 4111-0009 — Oct 2007
Jan. 2009
OPERATION
End Loading/Unloading — Platform at Cross-Traffic Position.
End Loading/Unloading — Platform at Below-Dock Position.
5. If truck/trailer bed is below the dock floor level,
perform steps 6 –12.
4. If truck/trailer bed is at or above dock floor level,
leave leveler at the cross-traffic position and
proceed with loading or unloading.
NOTE: If ramp loading is required, see Ramp
Loading/Unloading Instructions on page 19.
End loading or unloading can be done with
the dock at the cross-traffic position or
below-dock position, depending on the height
of the truck/trailer bed.
1. Check to make sure truck/trailer is positioned
squarely against dock bumpers.
2. Instruct driver to remain at the dock until the
loading or unloading process has been completed.
3. Chock the truck/trailer wheels or use the truck
restraint if available.
End Loading/Unloading Instructions
6. Push the Raise button to the platform high
enough to clear the lip keepers, but not high
enough to extend the lip.
7. Walk out on the leveler, pull and hold the safety
leg retract pull ring (B) (located in the recess at
the front of the platform). This will cause the lip to
extend away from the lip keepers and the cross
traffic safety legs to fold to allow the leveler to
lower to the below dock position.
8. When the platform lip clears the lip keepers,
continue to hold the pull chain as the leveler
lowers to the below-dock service position. The
platform will drift down to the full below-dock
position.
9. Proceed with loading or unloading.
NOTE: When end unloading is finished and access
to the rest of the truck/trailer is still required,
the platform lip will need to be extended. See
Ramp Loading/Unloading Instructions on
page 19 for further instructions.
10. When the loading or unloading is finished, return
the dock leveler platform to the cross-traffic
(stored) position.
11. Push the Raise button (B) until the lip clears the
lip keepers. Release Raise button, leveler will
return to the stored or cross traffic position.
12. Remove chocks from truck/trailer wheels or
release the truck restraint if used.
13. Indicate to the driver that the truck may leave the
dock.
Operating Instructions—Continued
End Loading/Unloading — Platform Too High
Use Below-Dock Position.
