23 4111-0009 — Oct 2007
Jan 2009
MAINTENANCE
Regular maintenance must be performed on a
weekly and quarterly schedule.
Weekly Maintenance
• Operate the dock leveler through the complete
operating cycle to maintain lubrication.
NOTE: To thoroughly inspect the platform hinge
area, put the platform in the full below-dock
position.
• Inspect the platform hinge and the lip hinge areas.
The hinge areas must be kept free of dirt and
debris. Build-up of foreign material in the hinge
areas will cause abnormal operation.
• Inspect the area under the platform, around and
under the air bag. Build-up of foreign material in
this area may damage air bag components,
causing abnormal operation.
Quarterly Maintenance
• Perform Weekly Service Items
• Lubricate the following areas with light weight
machine oil:
(A)— Lip hinge area unless equipped with
grease fittings (apply oil to the top of
the entire length of lip hinge when platform is
at the full below-dock position and lip is
folded)
(C)— Platform hinge area (apply oil to top of all
platform hinges when platform is at the full
below-dock position)
(G)— Lip lifter and lift cylinder pin
NOTE: Apply grease to lip hinge grease fittings if
equipped.
• Lubricate the following areas with light-weight
machine oil:
(B)— Lip maintenance prop pivot
(C)— Lip link pivots
(F)— E-Z release bellcrank pivot
(H)— Hold-down pivot/pulley
(J)— Safety leg linkage pivots
• Lubricate the following areas with white lithium
grease (if equipped with grease fittings):
(A)— Lip hinge area (inject grease into all the lip
hinge grease fittings)
(D)— Platform hinge area (inject grease into all the
platform hinge grease fittings)
(K)— Lip assist pin
IMPORTANT
Failure to properly lubricate the dock leveler will
cause abnormal operation of the leveler.
