PARTS
ITEM QTY
SIZE/CAPACITY
DESCRIPTION
PART NUMBER (15”) LIP
PART NUMBER (17”LIP)
1
1
6620/25
Lip Plate & Hinge Assembly
DOTH-4068
DOTH-4069
1
6630
Lip Plate & Hinge Assembly
DOTH-4070
DOTH-4071
1
6635
Lip Plate & Hinge Assembly
DOTH-4072
DOTH-4073
1
7220/25
Lip Plate & Hinge Assembly
DOTH-4074
DOTH-4075
1
7230
Lip Plate & Hinge Assembly
DOTH-4076
DOTH-4077
1
7235
Lip Plate & Hinge Assembly
DOTH-4078
DOTH-4079
1
7820/25
Lip Plate & Hinge Assembly
DOTH-4080
DOTH-4081
1
7830
Lip Plate & Hinge Assembly
DOTH-4082
DOTH-4083
1
8420/25
Lip Plate & Hinge Assembly
DOTH-4084
DOTH-4085
1
8430
Lip Plate & Hinge Assembly
DOTH-4086
DOTH-4087
2
1
6620/25
Center Plate & Hinge Assembly
DOTH-4088
1
6630
Center Plate & Hinge Assembly
DOTH-4089
1
6635
Center Plate & Hinge Assembly
DOTH-4090
1
7220/25
Center Plate & Hinge Assembly
DOTH-4091
1
7230
Center Plate & Hinge Assembly
DOTH-4092
1
7235
Center Plate & Hinge Assembly
DOTH-4093
1
7820/25
Center Plate & Hinge Assembly
DOTH-4094
1
7830
Center Plate & Hinge Assembly
DOTH-4095
1
8420/25
Center Plate & Hinge Assembly
DOTH-4096
1
8430
Center Plate & Hinge Assembly
DOTH-4097
3
1
ALL
Base Plate & Hinge Assembly
Consult Factory
4
2
6620/25/30
Hinge Pin
DOTH-3104
2
6635
Hinge Pin
DOTH-4312
2
7220/25/30
Hinge Pin
DOTH-3122
2
7235
Hinge Pin
DOTH-4313
2
7820/25/30
Hinge Pin
DOTH-3946
2
8420/25/30
Hinge Pin
DOTH-3920
5
2
All
Rivet - Button
DOTH-2400
6
2
All
Rivet - Flat
DOTH-2398
7
All
Extra Hvy Duty Bumper Blocks
DBBS-3500
8
2
All
HL LInkage Adder Assembly
DOTH-3675
9
2
All
X-Gusset
DOTH-3589
10
1
66/7220-30
NLI Operating Link Assembly
DOTH-3726
1
78/84
NLIII Operating Link Assembly
DOTH-3696
1
35K Only
NLIII Operating Link Assembly
DOTH-3697
11
1
66/7220-30
NLI Handle Assembly (Tube)
DOTH-3752
1
Optional
NLI Handle Assembly (Solid)
DOTH-3769
1
78/84
NLIII Handle Assembly
DOTH-3694
12
1
All
Extend Link Arm
DOTH-3585
13
1
All
Extend Link Arm Stop
DOTH-3586
14
2
All
Pivot Block
DOTH-3316
15
1
All
Shoulder Bolt
DOTH-2061
16
1
All
Locknut
DOTH-2136
17
1
All
Lip Stop
DOTH-3734
18
1
All
Pivot Block
DOTH-3597
19
2
All
Cotter Pin
DOTH_2375
20
1
All
Spring
DOTH-2559
21
1
All
NLIII Handle Holder
DOTH-3695
