PARTS
ITEM QTY
SIZE/CAPACITY
DESCRIPTION
PART NUMBER (15”) LIP PART NUMBER (17”LIP)
1
1
6620/25
Lip Plate & Hinge Assembly
DOTH-4047
DOTH-4048
1
6630
Lip Plate & Hinge Assembly
DOTH-4049
DOTH-4050
1
6635
Lip Plate & Hinge Assembly
DOTH-4051
DOTH-4052
1
7220/25
Lip Plate & Hinge Assembly
DOTH-4053
DOTH-4054
1
7230
Lip Plate & Hinge Assembly
DOTH-4055
DOTH-4056
1
7235
Lip Plate & Hinge Assembly
DOTH-4057
DOTH-3167
1
7820/25
Lip Plate & Hinge Assembly
DOTH-4058
DOTH-4059
1
7830
Lip Plate & Hinge Assembly
DOTH-3924
DOTH-4060
1
8420/25
Lip Plate & Hinge Assembly
DOTH-3156
DOTH-3155
1
8430
Lip Plate & Hinge Assembly
DOTH-3159
DOTH-4061
2
1
6620/25
Center Plate & Hinge Assembly
DOTH-4062
1
6630
Center Plate & Hinge Assembly
DOTH-4063
1
6635
Center Plate & Hinge Assembly
DOTH-4064
1
7220/25
Center Plate & Hinge Assembly
DOTH-4065
1
7230
Center Plate & Hinge Assembly
DOTH-4066
1
7235
Center Plate & Hinge Assembly
DOTH-3258
1
7820/25
Center Plate & Hinge Assembly
DOTH-4067
1
7830
Center Plate & Hinge Assembly
DOTH-3923
1
8420/25
Center Plate & Hinge Assembly
DOTH-3242
1
8430
Center Plate & Hinge Assembly
DOTH-3241
3
1
ALL
Base Plate & Hinge Assembly
Consult Factory
4
2
6620/25/30
Hinge Pin
DOTH-3104
2
6635
Hinge Pin
DOTH-4312
2
7220/25/30
Hinge Pin
DOTH-3122
2
7235
Hinge Pin
DOTH-4313
2
7820/25/30
Hinge Pin
DOTH-3946
2
8420/25/30
Hinge Pin
DOTH-3920
5
2
All
Rivet - Button
DOTH-2400
6
2
All
Rivet - Flat
DOTH-2398
7
2
All
Extra Hvy Duty Bumper Blocks
DBBS-3500
8
1
6620/25/30, 7220/25
Spring Linkage Assy - X-Regular
DOTH-3618
1
6635,7230,7820/25,
8420/25
Spring Linkage Assy - X-Hvy Duty
DOTH-3630
1
7235, 7830/35, 8430
Spring Linkage Assy - 3 Spring
DOTH-3626
9
2
All
X-Gusset
DOTH-3589
10
-
All
Secondary Gussets
DOTH-3319
11
1
66/7220-30
NL Roller Arm Assembly - Open
DOTH-3834
1
78/84
NLIII Operating Link Assembly
DOTH-3696
1
35K Only
NLIII Operating Link Assembly
DOTH-3697
12
1
66/7220-30
NL Pipe Handle Assembly
DOTH-3833
1
66/7235 - 78/84
NLIII Hanlde Assembly
DOTH-3694
13
1
All
Extend Link Arm
DOTH-3585
14
1
All
Extend Link Arm Stop
DOTH-3586
15
2
All
Pivot Block
DOTH-3316
16
1
All
Shoulder Bolt
DOTH-2061
17
1
All
Locknut
DOTH-2136
18
1
All
Lip Stop
DOTH-3734
19
1
All
NLIII Handle Holder
DOTH-3695
