Parts, Monarch power pack assembly – Poweramp EH SERIES HYDRAULIC User Manual
Page 46
44
4111-0004 —November 2003
Rev “B” February 2011
PARTS
Monarch Power Pack Assembly
Pump
Motor
G
I
F
H
E
D
A
A
B
C
J
K
Valve Block
Notes:
Low: Voltage: connect as shown
High: Voltage: Move lead J to Term. 3
move Lead 2 to Term. 4.
Monarch PPAC Motor
460 Volt 3 PH
208/230 Volt 3 PH
6 5 4
T1 T2 T3
6 5 4
9 8 7
9 8 7
3 2 1
3 2 1
T1 T2 T3
115 Volt 1 PH
230 Volt 1 PH
