Page 45
43
4111-0004 —November 2003
Rev “B” February 2011
PARTS
1
Provide dock leveler serial number and type of installation when calling or faxing orders.
2
Provide dock leveler serial number, voltage, and phase when calling or faxing orders.
Hoke / KTI Power Pack Components
Item Quantity
Part Number
Description
A
1
N/A
Motor, Hoke H8, 1.5HP, 1726 RPM, 1PH, 115/230V
N/A
Motor, Hoke H8, 1.5HP, 1726 RPM, 3PH, 208/230/460/575V
B
1
8581-0134
Coil & Nut for 8581-0133 Valve
C
1
8581-0133
Valve, 2 Way Normally Open
D
2
9301-0109
Fitting, #6 SAE to #6 JIC
E
1
8581-0130
Valve, Needle, NV1
F
1
N/A
Plug, N/A
G
1
8581-0128
Valve, Sequence, S1 (Red Tip)
H
1
8581-0129
Valve, Relief, RV1
J
1
8581-0136
Valve, Sequence, S2 (Silver Tip)
K
2
N/A
Screw, 5/16-18 UNC x 2.00
L
1
N/A
Coupler, Pump to Motor
M
1
0521-0007
Elbow, 90° 1/4 NPT Male x 1/4 Tube
N
1
0521-0161
Fitting, Reducer, Pipe, 3/4” NPTM to 1/4” NPTF
O
1
9391-0032
O-Ring, Power Pack
P
1
9391-0031
Breather, Hoke Power Pack
Q
1
9391-0030
Reservoir, 4 Quart, Hoke H8
R
4
N/A
Flange Bolt, 1/4-20 UNC x .50
S
1
N/A
Flange Bolt, 5/16-24 UNF x 3.50
T
1
N/A
Washer, Lock
U
1
9301-0209
Strainer, N/A
V
1
N/A
Nipple, 3/8 x 1 in Long
1
N/A
Elbow, 3/8 NPT, Plastic
W
1
N/A
Pump, PY-4.2, 1.97 GPM, Hoke H8
X
2
N/A
Fitting, Plug, Hollow Hex, Straight Thread, O-Ring #6 ORB, 9/16-18
Y
2
N/A
O-Ring, #6 ORB, 9/16-18 *Included with 9301-0105
Z
1
9301-0109
Fitting, #6 SAE to #6 JIC
AA
1
9301-0105
Fitting, Plug
AB
1
8581-0132
Valve, Relief, RV2
AC
1
8581-0131
Valve, PO Check
AD
1
N/A
Hoke Spacer
