Recommended
Tools
NOTE: Failure to follow an installation procedure could result in damage to equipment
or personal injury.
Additional warnings will be displayed throughout this manual for your awareness. These
warnings can be identified in warning boxes as shown in the following sample.
Andrew disclaims any liability or responsibility for the results of improper or unsafe
installation, operation, or maintenance practices.
Andrew supplies all appropriate hardware/parts required for the installation of your 9.3-
Meter Earth Station Antenna. All tools necessary for the installation process should be
provided by the installation crew. Andrew recommends the following tools to be used for
a proper installation of the 9.3-Meter Earth Station Antenna.
Tool Size Quantity
Open End or Combination Wrenches 1/4 Inch 2
5/16 Inch 2
3/8 Inch 2
7/16 Inch 2
1/2 Inch 2
9/16 Inch 2
3/4 Inch 2
7/8 Inch 2
1-1/16 2
1-1/8 Inch 2
1-7/16 Inch 2
1-5/8 Inch 2
1-7/8 Inch 2
Drive Sockets 5/16 Inch 2
7/16 Inch 1
1/2 Inch 2
9/16 Inch 2
3/4 Inch 2
15/16 Inch 2
1-1/16 Inch 1
1-1/8 Inch 2
1-7/16 Inch 1
1-7/8 Inch 1
Breaker Bar 3/4 Inch 2
Crane 18 Ton Minimum Capacity, extended end 1
Nylon Web Slings (2000 pound breaking strength) 3 Inch by 20 Foot 4
Rope or Cord (2000 pound breaking strength) 50 Foot 1
Shackles 5/8 Inch 4
Ladder 10 Foot Step 2
Ladder 18 Foot Extension 2
Drift Pin 5/8 to 7/8 Inch 2
Drift Pin 1/4 to 1/2 Inch 2
Spud Wrench 1-1/8 Inch 2
Screw Drivers Standard/Phillips 1
Bucket Truck 1
Allen Wrenches Set 1
Torque Wrench 250 ft/lb 1
Adjustable Wrenches 8 and 12 Inch 1
Drill Electric 1
Tape Measure (or other measuring device) Standard 1
Felt-tip Marker (or other marking device) Standard 1
Hammer Standard 1
Rubber Mallet Standard 1
Pry Bar Standard 1
Tin Snips Standard 1
Safety Gloves (each installer) Standard 1
Table 2-1. Recommended Tools
7
Getting Started
