Perrycraft SportQuest Track-mount - Sheet Metal User Manual

Roof rack - sm

CONTENTS:

2-Side Rail Assemblies, 2-Crossbars, 4-Stanchion Assemblies,

1-Hardware Pack (4-Crossbar End Caps, 4-Stanchion/T

rack Clamp Brackets,

4-Adjustment Knobs, 4-3/16 Drive Rivets, 4-Stanchion Plugs, 4-1/4"-20 x 7/8,

Socket-head Cap Screws, 4-1/4" Flat

ashers, 4-1/4"-20 Nylock Nuts, 4-Side Rail

End Caps, 4- T

ie Down Loops, *-#10 x ½ Bi-waxed T

russ-head Screws, 4-#10

x ¾ Bi-waxed Pan-head Screws, 1-3/16"

Allen W

rench, 1-Instruction Sheet, and

1-W

arranty/Consumer Information Card). * - Quantity of #10 x ½ Screws enclosed

will vary according to side rail (track) length.

OOLS REQUIRED:

T
ape Measure, Power Drill, 1/8 & 3/16 Drill Bits, Phillips

Screwdriver

, Flat-blade Screwdriver

, Hammer

, 7/16"

rench or

Adjustable

rench,

Non-permanent Marker

, and Metal-cutting Saw (if Option 2 is chosen).

This Pass-Thru/Stanchion-Fit model pr

ovides the choice of two configurations

of the stanchions and cr

ossbars at the time of installation:

Option 1.

Pass-Through Crossbars: Extend the

crossbars through the stanchions.

See reverse side of this sheet.

Option 2.

Stanchion-Fit Crossbars:

Cut the crossbars

to appropriate length to provide exact

fit between the stanchions

. See

Page 3 of this instruction sheet.

PRE-ASSEMBL

This roof rack kit is supplied with 4/T

ie Down Loops

for securing loads to the side rails (tracks). Prior to

assembly of either Option 1 or 2 above, insert

2 tie loops into each side rail (track) as shown,

slide to center of rail.

(over)

INSQ-TMOP-SM (1 of 3)

120918

Roof Rack - SM

rack-Mount Style with Optional Pass-Thru/Stanchion-Fit Hardware

Sheet Metal Roof Installation

W
ARNING:

The mounting hardwar

e included in this rack is not

recommended for

use on fiberglass or

composite material truck covers.

If installing this unit on a fiber

glass / plastic surface, please obtain

supplemental hardware pack HWSTTC-UV

from your distributor or contact

PERR

YCRAFT

, INC. at 800-777-7081

for additional assistance or technical

support if needed.

CAUTION:

External roof racks do not increase the GVWR of the vehicle. Maximum

load for this rack is 180 lbs. Evenly distributed on crossbar assemblies. Keep in

mind that torque applied to any straps, cords, etc. between the load and the vehicle

body ef

fectively add "load weight" to crossbars and the roof. Lar

ge or flat items

such as plywood or watercraft can trap air and create wind lift. Secure the ends of

such objects directly to the vehicle bumpers or tie downs. Bulky or tall loads can

create tremendous horizontal wind resistance from headwinds and crosswinds.

Extreme caution should be used when transporting such loads, taking into consideration

road conditions, vehicle speed, crosswinds, load securing methods, etc. Lar

ge, bulky

tall or flat objects should be properly secured to both crossbars and other attachment

points on the vehicle body

. PERR

YCRAFT

, Inc. does not assume responsibility for

style or size of rack installed, improper rack installation, exceeding rack load limit,

load securement methods, vehicle roof strength, wind lift or any other factors beyond

its control.

All fasteners, knobs, and load secur

ements should be checked

equently and tightened as necessary

est fit the rack befor

e drilling any mounting holes

. This rack fits many vehicles,

therefore the factory bow in the side rails (tracks) may or may not exactly match

the roof contour of the particular vehicle on which it is being installed. Prior to

attaching the crossbars, place the side rails on the vehicle roof in the approximate

location to be installed. The ends of the side rails should touch the roof surface and

the center of the rails should be no more than ½ of

f the roof surface. T

o adjust the

bow, place the empty carton on the ground as a cushion. Hold one end of the rail

in one hand, placing the other end on the carton and apply moderate pressure with

the other hand to the area of the rail needing adjustment.

IMPOR

ANT NOTE:

The enclosed W

arranty/Consumer Information card must

be fully completed by installation center and reviewed with the consumer (end-user),

and given to the consumer

. In the event of a potential warranty issue, failure by the

consumer to provide Mfg. with a copy of the completed document will void warranty

coverage.

Side Rail

ie-down loop
