34 46-648 Jupiter Magnetostrictive Transmitters
2.7 Specifications
2.7.1 Performance
Accuracy ±0.015"
Repeatability ±0.005% of full span or 0.005" (0.127 mm) (whichever is greater)
Linearity 0.020% of full span or 0.031" (0.794 mm) (whichever is greater)
Maximum level rate of change 6 inches per second (models with HART)
Response time 0.1 second
Warm-up <5 second
Upper dead zone None
Lower dead zone <2" (5 cm), SIL 2: <5" (13 cm)
Ambient temperature range Transmitter: -40° to +175° F (-40° to +80° C)
LCD: -10° to +160° F (-20° to +70° C)
Process temperature External Mount: -40° to +248° F (-40° to +120° C)
-320° to +850° F (-195° to +455° C) (with factory insulated MLI)
Direct Insertion: -40° to +200° F (-40° to +95° C)
-40° to +500° F (-40° to +260° C) (high temperature probe)
Humidity 0 to 99% non-condensing
Electromagnetic compliance EN 61326
Environmental protection compliance EN 60654-1
Drop protection compliance EN 50178
Surge Protection Compliance EN 61326 (1000 V)
Maximum Pressure (Direct Insertion) 1700 psig @ +100° F (117 bar @ +38° C)
(limited to the pressure rating of the selected flange or float)
