2. Electrical Service Specifications (Steam)
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT:
NOTES: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
When fuses are used they must be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse value,
by applying either local and/or National Electrical Codes to listed
appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) motor curve type ONLY.
For others, calculate/verify correct breaker size according to appliance
amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
APPROX.
AMP DRAW
CIRCUIT
BREAKER
60 Hz
50 Hz
208
3ш
3, 4
106
—
150
240
3ш
3
100
—
150
230
3ш
3
—
107
150
380
3ш
3, 4
—
60
90
400
3ш
3, 4
—
57
90
416
3ш
3, 4
—
58
90
460
3ш
3
53
—
80
480
3ш
3
53
—
80
7/14/08
IMPORTANT: The dryer must be connected to the electric supply shown on the data label, which is
located in the right hand side of the main electrical enclosure. In the case of 208 VAC
or 230/240 VAC, the supply voltage must match the electric service specifications of
the data label exactly.
WARNING: 208 VAC AND 230/240 VAC ARE NOT THE SAME. Any damage done to the
dryer components due to improper voltage will automatically VOID THE WARRANTY.
NOTE: For 4-wire service, cap the neutral.
NOTE: Contact the factory for electrical information not listed.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
