D. EXTERNAL SUPPLY CONNECTIONS
1. Compressed Air Supply
A minimum requirement of 20 cfh (0.57 cmh) at 80 psi (5.51 bar) of dry, clean and regulated compressed
air must be supplied to the dryer.
The compressed air supply must be connected into the 3/8” F.P.T. fitting, which is located in the rear
corner of the lower heat console section.
