Power Travel Adapter Hose
1
6084122
32
DESCRIPTION
QTY.
PART NO.
ITEM
OPTIONAL
ITEM
PART NO.
QTY.
DESCRIPTION
1
3200100
1
Coupler, 3/4" Quick Disconnect
2
3200310
1
Tee, 3/4" M. to 3/4" F. Pipe Run
3
3200311
1
Reducer, 3/4" M. to 1/4" F. Pipe
4
3200530
2
Elbow, 1/8" to 1/4" Male Pipe
5
3200314
2
Nipple, 1/8" Quick Disconnect
6
3200315
2
Coupler, 1/8" Quick Disconnect
7
6084020
1
Hyd. Hose Assy, 1/4" X 21" Long
8
3200137
3
Hex Nipple, 3/4" NPT
9
3200005
1
Ball Valve, 3/4" Pipe
10
3200133
2
Swivel, 3/4" M. to 3/4" F. Pipe
11
3200138
2
Adapter, 1" O-Ring to 3/4" F. Pipe
12
2900627
4
Cap Screw, Soc. Hd., #10-24 x 3-5/8"
13
3200547
1
Directional Valve
14
3200506
1
Valve, Pressure Control
15
3200551
3
Elbow, 3/8" O-Ring to 1/4" M. JIC
16
3200143
1
Subplate
17
3200101
1
Nipple, 3/4" Quick Disconnect
18
6050041
1
Adapter, 3/4" M. to 3/4" F. Pipe, Drilled
19
6084021
1
Hyd. Hose Ass'y, 1/4" x 5" Long
20
3200375
2
Adapter, 3/8" O-Ring to 1/4" M. JIC
21
2900898
4
Cap Screw, Soc. Hd., 5/16-18 x 5/8"
22
2600346
1
Hydraulic Motor, 1.88 CIR
23
2700233
1
Woodruff Key #404, 1/8" x 1/2"
24
3200115
1
Elbow, 3/8" O-Ring to 1/4" F. Pipe
25
3200057
1
Elbow, 1/4" M. Pipe to 1/4" M. JIC
26
6084060
1
Valve Assembly Bracket
27
2900144
2
Cap Screw, Hex Hd., 1/4-20 x 3/4"
28
2900024
2
Lock Washer, 1/4" Split
29
6084062
1
Hyd. Hose Assy, 1/4" x 9" Long
30
6084064
1
Hyd. Hose Assy, 1/4" x 5-1/2" Long
31
2900399
2
Cap Srew, Soc Hd., 1/4-20 x 1-1/2"
HYDRAULIC ASSEMBLY
#6050201
