Diamond Products SC3000 - Manual (Page 7)

SC3000 Chassis Subassembly 6040565 Parts List
ITEM PART NO. QTY. DESCRIPTION
1 6040479 1 Base Frame Weldment SC3000
2 2502052 2 32" Vertical Shaft
3 2505522 1 Foot Rest Plate
4 6040573 1 Rear Axle Assembly
5 2900173 2 Hex Nut, 1"-14 Right Hand
6 6040572 1 Auburn Drive Subassembly SC3000
7 3200820 1 Mechanical Brake Caliper
8 2900127 4 Flat Washer, 1/2" USS
9 6040574 1 Steering Link, Wheel Subassembly SC3000
10 6040578 2 Engine Support Weldment
11 6011454 2 Brace, Head Shaft
12 2900866 4 Cap Screw, Hex Hd., 3/4-10 x 2"
13 2900042 4 Lock Washer, 3/4" Split
14 6011455 1 Cylinder Pin 1"
15 2505530 1 Foot Guard
16 2502775 1 Operator's Seat
17 2503424 1 Sprocket/Chain Guard
18 2900031 4 Lock Washer, 5/16" Split
19 2900141 4 Hex Nut, 5/16-18
20 2900147 2 Cap Screw, Hex Hd., 5/8-11 x 1-3/4"
21 2900196 2 Cap Screw, Hex Hd., 3/8-16 x 3/4"
22 2900018 2 Lock Nut, 3/8-16 Nylon
23 2900139 2 Cap Screw, Hex Hd., 1/2-13 x 1-3/4"
24 2900084 2 Lock Washer, 1/2" Split
25 2900509 2 Cap Screw, Hex Hd., 1/2-20 x 4"
