ITEM

PART NO.

QTY.

DESCRIPTION

1

6040479

1

Base Frame Weldment SC3000 (Partial Display)

2

6040401

1

RH Steering Spindle

3

6040402

1

LH Steering Spindle

4

2503558

2

King Pin

5

2502772

1

LH Ball Joint Linkage

6

2502773

1

RH Ball Joint Linkage

7

2503461

1

Tie Rod

8

2903145

1

3/4-16 Jam Nut LH

9

2903144

1

3/4-16 Jam Nut RH

10

2503497

2

Tapered Roller Bearing 1-3/8 Inner

11

2503496

2

Tapered Roller Bearing 1-1/16 Inner/Outer

12

3201344

2

Seal, Double Lip

13

2503499

2

Idler Hub, Studded

14

2502934

2

Spindle Washer 1"

15

2903196

2

Spindle Nut 1"

16

2900971

2

1/8"X2" Cotter Pin

17

2503325

2

6" Wheel

18

2903195

10

1/2-20 Lug/Cone Nut

19

3200822

1

1-1/2 x 6 Double Actuator Cylinder

20

3200822-2

1

Cylinder Rod/Shaft

21

3200822-3

1

Clevis Pin

22

3200822-4

1

Cotter Pin

23

3200811

2

1/4" Flow Control

24

3200791

2

1/4" Brass Nipple
