Diamond Products CC7874XL - Manual (Page 40)

Steering Control Unit Assembly #6046029
ITEM PART NO. QTY DESCRIPTION
1 6043245 1 Steering Mount Weldment
2 6043244 1 Cup Holder Weldment
3 6043246 1 Steering Mount Plate
4 2900014 14 Flat Washer, 3/8" SAE
5 2900006 12 Lock Washer, 3/8" Split
6 2900196 9 Cap Screw, Hex Hd., 3/8-16 x 3/4"
7 2500577 1 Lever, Adjustable 3/8-16"
8 2600334 1 Steer Control Unit
9 2900314 4 Cap Screw, Hex Hd., M10 x 20mm
10 3200263 4 Adapter, 3/8" O-Ring to 3/8" M. JIC
11 3200521 1 Ball Valve-.50- 90 Degree
12 3200517 1 1/2"X3/8" Hose Barb Strait (Brass)
13 3200516 1 1/2" X 3/8" Hose Barb
14 2501170 1 Steering Wheel 14" DIA
15 3202163 1
Hyd Hose Orbital "P" Port to Front
Bulkhead
16 3202161 1
Hyd Hose Orbital "T" Port to Rear
Bulkhead
17 3202160 1
Hyd Hose to Bottom Rotary Act Port to
"L" Orbital Port
18 3202162 1
Hyd Hose Top Rotary Act Port to "R"
Orbital Port
19 2501176 1 Steering Wheel Cap
40
