Frame Components #6046003

ITEM PART

NO.

QTY

DESCRIPTION

1

6043272

1

Frame Weldment

2

6043276

1

Lift Frame

3

6043271

2

Pin, Cylinder Long

4

2400615

4

Set Collar, 3/4"

5

2900002

10

Flat Washer, 5/8" SAE

6

2900099

2

Cap Screw, Hex Hd., 5/8-11 x 3-1/2"

7

3200026

2

Water Valve, 1/2" FPT

8

2900038

4

Lock Washer, #10 Split

9

2900117

4

Cap Screw, Soc. Hd., #10-24 x 3/8"

10

2900502

3

Cap Screw, Hex Hd., 5/8-11 x 5"

11

3200008

1

Close Nipple, 1/2" NPT

12

3200013

1

Street Elbow, 1/2" NPT

13

3200022

1

Fitting, 1/2" F. Pipe to 3/4" F. Garden

14

3200516

5

1/2" X 3/8" Hose Barb

15

2501548

1

Spray Hose Assembly

16

3200517

1

1/2"X3/8" Hose Barb Strait (Brass)

17

2900135

5

Lock Nut, 5/8-11 Nylon

18

2400199

1

Locking Knob 3/8 Stud
