Diamond Products CB15E-XL User Manual
Page 17
4646174 CB15 XL PANEL ASSEMBLY
ITEM PART
NO.
QTY.
DESCRIPTION
1
4646141
1
Instrument Panel
2
2900022
8
Flat Washer, 5/16" SAE
3
2900031
6
Lock Washer, 5/16" Split
4
2900138
6
Cap Screw, Hex Hd., 5/16-18 x 1"
5
4646102
1
Manifold, SAE O-Ring
6
4646101
1
Manifold, 3/4 NPT
7
2900009
20
Flat Washer, 1/4" SAE
8
2901001
8
Cap Screw, Hex Hd., 1/4-20 x 2-1/2"
9
2900010
10
Lock Nut, 1/4-20 Nylon
10
3200479
2
Plug, 3/4" NPT Square Head
11
3201434
1
Plug, 1/2" SAE O-Ring Hex
12
3200285
1
Elbow, 1/2" O-Ring to 1/2" M. JIC
13
3201291
1
Adapter, 1/2"M.O-Ring to 1/4" MJIC
14
3200097
1
Adapter, 3/4" M. JIC to 3/4" M. Pipe
15
3200417
1
Elbow, 3/4" F. JIC to 3/4" M. JIC
16
3201522
1
Adapter, 3/4" M. Pipe to 1/2" M. JIC
17
3200330
1
Adapter, 3/4" M. Pipe to 3/4" O-Ring
18
3200371
1
Adaptor, 1/2" MPT to 1/2" O-Ring
19
3200105
1
Nipple, 1/2" Q.D.
20
3200101
1
Nipple, 3/4" Quick Disconnect
21
3200137
1
Hex Nipple, 3/4" NPT
22
3200383
1
Nipple, Hex, 3/4" MPT TO 1/2" MPT
23
3200100
1
Coupler, 3/4" Quick Disconnect
24
3200104
1
Coupler, 1/2" Q.D.
25
2400256
1
Heat Exchanger
26
2900303
2
Lock Nut, M8-1.25 Nylon Insert
27
3200400
2
Elbow, 3/4" O-Ring to 3/4" Male JIC
28
3201654
1
Valve, Flow Control
29
3200366
3
Elbow, 5/8" O-Ring to 1/2" Male JIC, 90 Deg.
30
2900245
2
Cap Screw, Soc. Hd., 1/4-20 x 2-5/8"
31
3200250
1
Gauge, Hydraulic, 3000 PSI
32
2500549
1
Plug, 7/8" Hole
33
2500204
1
Plug, 1/2" Hole
34
2503749
1
Plug, 5/16" Hole (Tapered)
35
3201659
2
Fitting, 3/4" M. Pipe to 3/4" M. Garden
36
3200177
1
Fitting, 3/4" F. Garden Union Swivel
37
1800536
1
"Return" Decal
38
1800941
1
Decal, Hydraulic Power Supply
39
1800531
1
"Hyd. Pressure" Decal
40
1801847
1
Decal, CB15 Flow Control
41
1800616
1
"Core Bore CB15E" Decal
17
