Diamond Products CC1100 User Manual
Page 5
SAW ASSEMBLY (REGULAR CUT), #5801015
ITEM
PART NO.
QTY
DESCRIPTION
1
6040702
1
Frame Weldment
2
6040609
1
Gas Engine Parts
3
6040610
1
Blade Shaft Assembly
4
6040708
1
Front Axle Assembly
5
6049031
1
14" Blade Guard Assembly
6
6040611
1
Hose Assembly with Water Valve
7
6048080
1
Pointer Assembly
8
6040613
1
Shaft, Belt Adjustment
9
6040713
1
Blade Guard Spacer
10
6040714
1
Tapered Guard Mount
11
6040718
1
Belt Guard Weldment
12
6040706
1
Sliding Handle Weldment
13
6010618
1
Bracket, Handlebar Lever
14
6010619
1
Lever, Handlebar
15
2503925
2
Cap, 1-1/2" Sq. Tube
16
2500001
2
7/8" Handle Grip
17
6040712
1
Rear Axle
18
2503754
2
Wheel 8" X 2" X 3/4"
19
2400615
4
Set Collar, 3/4"
20
2900014
9
Flat Washer, 3/8" SAE
21
2900079
2
Cap Screw, Hex Hd., 3/8-16 x 2-1/4"
22
2900056
2
Set Screw, Soc. Hd., 1/4-20 x 1/4"
23
2900319
2
Cap Screw, Hex Hd., M10 x 80mm
24
2901409
2
Cap Screw, Flat Hd. Soc., M10 x 50mm
25
2900331
1
Cap Screw, Hex Hd., M12 x 40mm
26
2900321
2
Lock Washer, M10 Split
27
2900327
1
Lock Nut, M12 Nylon
28
2900304
5
Lock Nut, M10 Nylon
29
2900307
2
Wing Screw, M6 x 16mm
30
2500256
2
Wrench Head
31
2900058
4
Flat Washer, 1/2" SAE
32
2900025
4
Cap Screw, Hex Hd., 1/2-13 x 1-1/4"
33
2900084
4
Lock Washer, 1/2" Split
34
2501565
1
Throttle Control, 15"
35
2900309
2
Cap Screw, Hex Hd., M5 x 20mm
36
2900301
2
Lock Nut, M5 Nylon
37
2900009
2
Flat Washer, 1/4" SAE
38
6048789
1
Wire Harness, Stop Switch
39
2900144
2
Cap Screw, Hex Hd., 1/4-20 x 3/4"
40
6040704
1
Plate, Belt Guard
41
2900024
2
Lock Washer, 1/4" Split
42
2900016
2
Flat Washer, #10 USS
