Diamond Products CC1100 - Manual (Page 3)

TABLE OF CONTENTS
Description Page No.
Saw Assembly (Normal Cut)………………………….…………..…….4 - 5
Saw Assembly (Up-Cut)………………………….……………..……... 6 - 7
Gas Engine Assembly ….……..………………………………………...…8
Blade Shaft Assembly …………………..…….……………….…………..9
Front Axle Assembly……………...……………………………………....10
Blade Guard Assembly …………………..…………………….………....11
Hose Assembly With Valve……….………………………….…………...12
Pointer Assembly…..……..………………………………………….…....13
Pointer Assembly (Up-Cut)…..……..……………………………….…....14
Notes…………………………………………………………………...….15
Warranty………………..…………………………………………… Rear Cover
Quick Reference Service Filters/ Belts
DP Part No. Description Manufacturer’s Part No.
2700201
Air Filter for 11HP Honda (Honda #17210-ZE3-505)
2703150 Fuel Filter for 11HP Honda (Honda #17672RZE2-W01)
2500380 Blade Shaft Belt (3) for 11HP Honda (Gates #3VX300)
