M88
© 2008 AS America Inc.
WASHBROOK™
URINAL
VITREOUS CHINA
NOTES:
FLUSH VALVE NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL SUPPORTS.
IMPORTANT: Dimensions of fixtures are nominal and may vary within
the range of tolerances established by ANSI Standard A112.19.2. These
measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
MEETS THE AMERICANS WITH DISABILITIES ACT GUIDELINES
AND ANSI A117.1 ACCESSIBLE AND USABLE BUILDINGS AND
FACILITIES - CHECK LOCAL CODES.
When installed so top of rim is 387mm (15-1/4") from finished floor.
6501.010 TOP SPUD
6506.011 BACK SPUD
BARRIER FREE
13mm
(1/2)
102mm
(4)
GASKET
2" N.P.T.
INSIDE THREADS
DETAIL OF OUTLET CONNECTION
FINISHED WALL
13mm
(1/2)
121mm
(4-3/4)
3/4
SPUD
3/4 S.P.S. OR 3/4 C.W.T.
SUPPLY TO FLUSH VALVE
438mm
(17-1/4)
692mm
(27-1/4)
REF.
457mm
(18)
292mm
(11-1/2)
89mm
(3-1/2)
102mm
(4)
470mm
(18-1/2)
343mm
(13-1/2)
C/L OF
OUTLET
K2 HANGERS
8mm X 25mm
(5/16 X 1)
SLOT
64mm
(2-1/2)
235mm
(9-1/4)
355mm
(14)
2" N.P.T.
FEMALE OUTLET
CONNECTION
13mm
(1/2)
FINISHED FLOOR
FINISHED
WALL
387mm
(15-1/4) MAX
610mm
(24)
OPTIONAL
13mm
(1/2)
102mm
(4)
GASKET
2" N.P.T.
INSIDE THREADS
DETAIL OF OUTLET CONNECTION
FINISHED WALL
13mm
(1/2)
3/4
SPUD
438mm
(17-1/4)
692mm
(27-1/4)
REF.
457mm
(18)
89mm
(3-1/2)
102mm
(4)
470mm
(18-1/2)
343mm
(13-1/2)
C/L OF
OUTLET
K2 HANGERS
8mm X 25mm
(5/16 X 1)
SLOT
51mm
(2)
51mm
(2)
235mm
(9-1/4)
355mm
(14)
2" N.P.T.
FEMALE OUTLET
CONNECTION
13mm
(1/2)
FINISHED FLOOR
FINISHED
WALL
387mm
(15-1/4) MAX
610mm
(24)
OPTIONAL
Revised 11/08
