TYLNY PANEL
19.
Gniazdo antenowe( typ SO239 ).
20.
Gniazdo S.Meter: pozwala podlaczyc zewnetrzny miernik sygnalu.
21.
Gniazdo “PA” : umozliwia podlaczenie tubowego glosnika zewnetrznego.
22.
Gniazdo”EXT” : sluzy do podlaczenia zewnetrznego glosnika
23.
Kabel 13.2 Vdc: zasila radiotelefon.
MIKROFON
1.
PTT: przycisk nadawania
2.
UP/DOWN przyciski:
manualna zmiana kanalow.
3.
6 pin zlacze mikrofonowe.
UP
DOWN
2
1
3
19
20
21 22
23
ANTENNA
S-METER
PA
EXT
