Morris PVC Flexible Hose
13
2240 W. 15th St., Erie, PA 16505
Phone: 814-459-1741
For Prices and Delivery
Call Toll Free: 1-800-426-1579
Toll-Free Fax: 1-800-545-1399
E-mail: [email protected]
www.morriscoupling.com
MORR-CLEAR
“
Economical Food-Grade
PVC Transfer Hose
Our most popular material-handling hose
features a clear PVC tube with a smooth
bore to provide excellent material flow
rates. A clear, rigid, external PVC helix
reinforcement enables user to visually
monitor flow of material.
High-density PVC materials are known for
their ability to withstand abrasion. Hose
construction provides good flexibility with
light weight. Hose carries FDA “3A Dairy”
rating. Operating temperature range from
10°F to 150°F.
Four distinct types to meet
varying application needs.
Morris offers material-handling hoses to
meet the wide variety of bulk conveying
system requirements which may be
encountered. Flexible hose is suitable
for both vacuum and pressure-discharge
service.
Morris hoses are ideal for conveying
pellets, granular material and powdery
substances. Flexible hose offers a fast,
convenient method of finishing a pneu-
matic conveying system.
Morris also offers clamps to help
complete your installation.
MORR-
Working
Vacuum
Bend
Standard
CLEAR
I.D.
O.D.
Pressure
Rating
Radius
Weight
Coils
Number
(inch)
(inch)
(psi)
(inch HG)
(inch)
(lbs./ft.)
(ft.)
MC150
1.5
1.81
50
29
3.2
0.31
50
MC45M
45mm
2.05
40
29
3.2
0.42
50
MC200
2
2.43
40
29
3.2
0.42
50
MC250
2.5
3.00
35
29
4.5
0.65
50
MC300
3
3.58
35
29
6.5
0.85
50
MC400
4
4.68
35
15
10.4
1.30
50
MC500
5
5.65
30
10
21.0
1.50
50
MC600
6
6.72
30
10
29.4
2.20
25
MORR-
CLEAR
Working
Vacuum
Bend
Standard
STATIC
I.D.
O.D.
Pressure
Rating
Radius
Weight
Coils
Number
(inch)
(inch)
(psi)
(inch HG)
(inch)
(lbs./ft.)
(ft.)
MS150
1.5
1.81
50
29
3.2
0.31
50
MS45M
45mm
2.05
40
29
3.2
0.42
50
MS200
2
2.43
40
29
3.2
0.42
50
MS250
2.5
3.00
35
29
4.5
0.65
50
MS300
3
3.58
35
29
6.5
0.85
50
MS400
4
4.68
35
15
10.4
1.30
50
MS500
5
5.65
30
10
21.0
1.50
50
MS600
6
6.72
30
10
29.4
2.20
25
MORR-CLEAR
“
STATIC
Food-Grade PVC Hose with
Static-Dissipating Ground Wire
This is the same durable lightweight hose
described above. The only difference is
MORR-CLEAR STATIC contains an integral
wire to assure a positive ground where
static build-up is a concern.
