Morris Metal Flexible Hose User Manual
Morris metal flexible hose, General purpose metal flex hose

Morris Metal Flexible Hose
15
2240 W. 15th St., Erie, PA 16505
Phone: 814-459-1741
For Prices and Delivery
Call Toll Free: 1-800-426-1579
Toll-Free Fax: 1-800-545-1399
E-mail: [email protected]
internet: www.morriscoupling.com
General Purpose Metal Flex Hose
This unlined general purpose hose features interlocked
construction formed from a single metal strip. The balanced
interlocking manufacturing process provides for maximum
flexibility and longest service life. Pressure and vacuum
capabilities may be easily enhanced by the selection of
an appropriate packing material.
The unlined metal flex-hose is available in various alloys,
metal strip thicknesses and in diameters from 1-1/2" through
8" I.D. Interlocked hose is available in any length and can be
provided in bulk or fabricated assemblies.
C
NOTE: Other diameters are available on request.
Packings Available For Increased Pressure and
Vacuum Capabilities
Packing Type
Features
Max. Temp.
Cotton
Most Economical Packing
180°F
Elastomeric
Provides Maximum Pressure
200°F
and Vacuum Capability
Copper
For High Temperatures
800°F
High Temperature
Specially Coated High
1,000°F
Fiber
Temperature Filament
Stainless Steel
For Extreme Temperatures
1,200°F
Morris Material Codes
Materials
A – Aluminum (unpacked only)
G – Galvanized Steel
S – T304 Stainless Steel
6
– T316 Stainless Steel
Technical data is meant to be used as a guide. If more specific
information is required, please contact the factory.
Packed
Unpacked
PACKING
Strip Thickness
10
15
18
25
30
20
Material Code
Material Code
Material Code
Material Code
Material Code
Material Code
G, S
G, S
G, S, 6
G, S
G
A
Weight
Min.
Weight
Min.
Weight
Min.
Weight
Min.
Weight
Min.
Weight
Min.
Inside
Per
Bend
Per
Bend
Per
Bend
Per
Bend
Per
Bend
Per
Bend
Dia.
Foot
Radius
Foot
Radius
Foot
Radius
Foot
Radius
Foot
Radius
Foot
Radius
(In.)
(Lbs.)
(In.)
(Lbs.)
(In.)
(Lbs.)
(In.)
(Lbs.)
(In.)
(Lbs)
(In.)
(Lbs.)
(In.)
1-1/2
0.5
6
0.7
7
0.9
7
1.3
8
1.6
8
2
0.7
8
1.0
9
1.1
9
1.7
10
2.0
11
2-1/2
0.8
10
1.2
11
1.4
11
2.1
12
2.5
13
3
1.0
11
1.4
12
1.6
13
2.5
15
2.9
15
3-1/2
1.1
13
1.6
14
1.9
15
2.8
17
3.4
18
4
1.2
15
1.8
16
2.2
17
3.2
19
3.8
20
0.9
19
4-1/2
1.4
17
2.0
18
2.4
19
3.6
21
4.3
22
1.0
21
5
1.5
19
2.2
20
2.7
21
4.0
24
4.7
25
1.1
24
6
1.8
22
2.7
24
3.2
25
4.7
28
5.6
29
1.3
28
7
3.1
28
3.7
30
5.5
33
6.5
34
1.5
33
8
3.5
32
4.2
34
6.2
37
7.4
39
1.8
37
