Micro-PWC
™ Installation & Setup Guide
Contents v
List of Figures
Figure 3-1. I/O Address List on Windows, Windows 2000 Professional ........... 15
Figure 3-2. I/O Address List on Windows XP Professional .............................. 16
Figure 3-3. Jumper Settings, Supervisor Board ............................................... 18
Figure 3-4. My Network Places Icon and Menu ................................................ 20
Figure 3-5. Configuring the IP Address, Steps 2 and 3 .................................... 20
Figure 3-6. Internet Protocol (TCP/IP) Properties ............................................ 21
Figure 3-7. Hardware Key for Use with Micro-PWC System Software
(Parallel Port Version) ................................................................... 22
Figure 3-8. Connecting the Computer’s COM Port to the Datalink ................... 25
Figure 3-9. 53SU6000Datalink SUPERVISOR Card to
Datalink Interconnection Diagram (ID-53-1610) ............................. 26
Figure 3-10. 53SU6000 Microlink SUPERVISOR Card to Microlink
Interconnection Diagram (ID-53-1597) .......................................... 27
Figure 4-1. Micro-PWC Program Group ........................................................... 41
List of Tables
Table 3-1. License Type and Operational Mode Interaction ............................. 32
Table 5-1. Micro-PWC Installation and Setup Problems and
Recommendations ........................................................................... 51
Table 7-1. Interconnection Terminal Boards (ITB) ............................................ 60
