IB-23C004
INTRODUCTION
1.4 TECHNICAL SUMMARY
POWER REQUIREMENTS
Input: 85 - 250 Vrms Universal Input
Output: 5V, 2A
Power Dissipation: 15W@125V
Switching Frequency: 30kHz
Detachable Power Cord (supplied cord may not be suitable for all input conditions)
North American Color Coding
Rated 105°C, 125V
Passes VW-1 Vertical Wire Flame Test
NEMA 5-15P Molded Vinyl Grounding Plug
UL/CSA Approved
Length: 6'7" (2 meters)
PHYSICAL CHARACTERISTICS
Dimensions
1733NZ10101A Length: 9.975 inches(253.35mm)
Width: 6.30 inches (160.02 mm)
Height: 2.75 inches (69.85 mm)
I/O Ports
Serial Port 1: J1, DB9 female
Serial Port 2: J2, DB25 female
ICN0: J3, 2-wire communications, ground
ICN1: J4, 2-wire communications, ground
ICN Connections: 18 AWG (1mm), twisted pair wire (an additional 18 AWG wire is
required to use the isolation feature as described in Section 2.3.2.).
Switches and Jumpers: See Appendix A
Microprocessor
Link Processor: 63B09E, 8 bit, 2 mHz dual phase clock
ICN Processor: 63B09E, 8 bit, 2 mHz dual phase clock
COMMUNICATIONS
Serial Port Transmission Standard: RS-232C
Serial Port Parity: None (not configurable)
Serial Port Baud Rates: 19200, 9600, 4800, 2400, 1200, 600, 300
ICN Baud Rates: 62500*, 31250
* Software support for this baud rate is currently unavailable.
1-5
