Page 4

92902-93
2051F Conversion Instructions for Foxboro SPEC 200
2.
Remove the SPEC 200 instrument display from its shelf position. Disconnect the instrument cable
from the back of the display.
3.
Connect the direct connect cable of the MODCELL 2051R into the SPEC 200 instrument cable.
Take care for correct orientation of pins.
4
Slide the MODCELL 2051R into the shelf position until the top bracket secures the instrument firmly
in place. If instrument power is not received through the instrument cable, connect power to the
MODCELL 2051R terminal block.
Panel Installation Procedure
1.
The following steps describe intermediate installation replacement of the Foxboro SPEC 200
instrument when making connections directly at the back of the MODCELL 2051R instrument.
2.
For quickest change-out, pre configure the MODCELL 2051R controller prior to panel installation.
3.
Remove the SPEC 200 instrument display from its shelf position. Disconnect the instrument cable
from the back of the display. You may elect to remove the instrument cable all together or coil the
cable and leave in the back of the tray.
4.
Make power and field connections per I/O instructions in IB-23C650-_._
5.
Apply power and tune the instrument as required for the loop.
