53ML5100A Manual Loading Station
Supplement to the Instruction Bulletin
Configuration Requirements 5
3.0 CONFIGURATION REQUIREMENTS
, Communication Module, Column 3 (Set Up) for the appropriate configuration values.
Table 3-1. Communication Module
Title
Data-
point
Set Up
Default
Attribute
Address
B01
Select
Address
0
It identifies the address of this instrument on the Datalink
network. Each unit connected to the Datalink network must
have its own unique address. Valid addresses are from 0-31.
Baud
Rate
B02
Select
a
Baud
Rate
253
This datapoint value designates the baud rate of the Datalink
network. The baud rate must be the same for all of the
instruments connected to the same Datalink network.
Datapoint values and their corresponding baud rates are as
follows:
Value
Baud Rate
OR
Value
Baud Rate
255
28800
9
28800
254
14400
8
14400
N/A
N/A
7
19200
253
9600
6
9600
250
4800
5
4800
244
2400
4
2400
232
1200
3
1200
208
600
2
600
160
300
1
300
N/A
N/A
0
110
No
Parity
L256
0
0
This datapoint indicates if parity generation and checking
should be turned on or off. It is set to 0 for even parity serial
byte protocol. It is set to 1 for no parity protocol.
No Byte
Stuffing
L258
0
0
When set to a 1, this datapoint disables the standard MicroMod
communication protocol feature which inserts a 00 (NUL) byte
after every 7E
H
(SOH) that is not the beginning of a message.
(This permits user-written communications software to
determine the number of bytes to expect in a response
message.) It must be set to 0 when using MicroMod
communications software or equipment.
Datalink
Disable
L257
0
0
When set to 0, it permits full Datalink communication
capabilities.
When set to 1, it disables Datalink communication capabilities.
