Meriam M1 – Series Digital Manometer - Manual (Page 13)

M1 Series - DM Instruction Manual 9R000034-IR
E.O. 6409 JAN 2008
www.meriam.com
Page 13 of 17
Battery Type:
3 x AA battery, field replaceable.
Alkaline (A900614-00011):
Duracell, PC1500, 1.5V, 2000mAh
Duracell, MN1500, 1.5V, 2000mAh
Varta, 4906, 1.5V, 2600mAh
Battery Operation:
> 300 hours continuous use without backlight on, 1 year
shelf life, auto power off set at 30 minutes, low battery
warning giving approximately 2 hours of run time.
Enclosure:
(6.5” Ч 3.2” Ч 1.1”) Polycarbonate, Permanently Static
Dissipative, ESD Protection
Enclosure with Boot: (6.8” Ч 3.5” Ч 1.3”)
Display Resolution:
Range 0-9 0-99 0-999 0-9999
Display x.yyy xx.yy xxx.y xxxx
Some pressure units may display differently depending upon
full scale range and accuracy.
Display Warnings
° HI = The temperature of M1 above valid calibration
range/field recalibration value.
° LO = The temperature of M1 below valid calibration
range/field recalibration value.
P HI = Pressure applied to M1 above valid calibration
range/field recalibration value.
P LO = Pressure applied to M1 below valid calibration
range/field recalibration value.
