Model USCH-10001 USCH-20001 USCH-30001 USCH-10002 USCH-20002 USCH-30002
INPUT
Voltage Range
60Vac – 144Vac Software Selectable 120Vac – 288Vac Software Selectable
Frequency 50/60 Hz Auto-Select, +/- 5Hz
Phase/Wire Line + Ground
Power Factor >0.99 at Rated Full Linear Load
Transfer Time 0 ms
AC Leakage Current 5mA <3.5mA
Surge Protection 400 joules 300 joules
OUTPUT
Capacity
1kVA/800 Watts 2kVA/1600 Watts 3kVA/2400 Watts 1kVA/800 Watts 2kVA/1600 Watts 3kVA/2400 Watts
Voltage 100/110/115/120/127Vac Software Selectable 200/208/220/230/240Vac Software Selectable
Voltage Regulation +/- 1%
Frequency
(Sync Range)
3Hz or 1Hz Software Selectable
Frequency
Battery Mode
+/- 0.1% (0.05 ~0.06Hz)
Crest Factor 3:1
Harmonic Distortion < 3% THD (Linear Loads), < 7% THD (Non-Linear Loads)
Transient Response < = 60ms/5%
Waveform Pure Sine Wave
Effi ciency AC Mode 85% 85% 88% 85% 85% 88%
Effi ciency Bat. Mode 83% 83% 85% 83% 83% 85%
DC Start Yes
Cooling Load Dependent Variable Speed Fans
Over temperature Normal Mode -Transfer to bypass; Battery Mode – UPS shuts down immediately
Overload <105% continuous, >120% for 30 seconds, >150% for 10 seconds
DISPLAY, ALARMS, DIAGNOSTICS, COMMUNICATIONS & EMERGENCY FUNCTION
Status On LCD
Line Mode, Backup Mode, ECO Mode, Bypass Supply, Battery Low, Battery Bad/Disconnected, Overload,
Transferring with interruption & UPS Fault
Readings On LCD Input Voltage, Input Frequency, Output Voltage, Output Frequency, Load Percentage, Battery Voltage & Units Inner Temperature
Power Up ON/OFF Button, Test Alarm & Reset Button
Self-Diagnostics Upon Power –On, Front Panel Setting & Software Control, 24 Hour self check
Audible Alarms and Visual Line Failure, Battery Low, Transfer to Bypass, System Fault Conditions
Communications RS232 Serial Port and USB, optional SNMP/WEB, USB or Dry Contact Cards
Emergency Power Off
(EPO) Connection
Emergency Power Off shuts down UPS when activated by customer supplied EPO Circuit
CONNECTIONS
Input 6' Cord w/ 5-15P 6' Cord w/ 5-20P 6' Cord w/ L5-30P
6' Cord with 10A,
IEC 320-C14
6' Cord with 10A,
IEC 320-C146’
6' Cord with 16A,
IEC 320-C20
Output (6) 5-15R
(2) 5-15R &
(2) 5-20R
(4) 5-15R &
(1) L5-30R
(6) 10A,
IEC 320-C13
(6) 10A,
IEC 320-C13
(4) 10A,IEC 320-C13
& (1) 16A,
IEC 320-C19
Output Control (2) ON/OFF Software controlled receptacle banks for load shedding
PHYSICAL
Dimensions
H" x W" x D" Rack Confi guration 1kVA 3.5 x 17.3 x 16 2/3kVA 3.5 x 17.3 x 25.6
Tower Confi guration 1kVA 17.3 x 3.5 x 16 2/3kVA 17.3 x 3.5 x 25.6
Weight (lbs.) 34.5 64.7 65.3 34.5 64.7 65.3
Safety and Performance
UL1778, c-UL, CE, IEC/EN 62040-1-1, IEC 60950-1, IEC/EN 62040-2 Class A, IEC/EN55011, CISPR11, IEC61000-4-2/-3/-4/-5,
IEC61000-2-2, IEC61000-3-2/-3,FCC Part 15 Subpart B Class A
ENVIRONMENTAL
Operating Temp.
0° C – 40° C
Noise Level <50dBA @ 1 Meter
Relative Humidity 0 to 90% non-condensing
INTERNAL BATTERY
Battery Run Time
@ Full Load
7 Minutes 5 Minutes 7 Minutes 5 Minutes
Type 3 each, 12V/7AH
Sealed Lead Acid
Maintenance Free
6 each, 12V/7AH
Sealed Lead Acid
Maintenance Free
6 each, 12V/9AH
Sealed Lead Acid
Maintenance Free
3 each, 12V/7AH
Sealed Lead Acid
Maintenance Free
6 each, 12V/7AH
Sealed Lead Acid
Maintenance Free
6 each, 12V/9AH
Sealed Lead Acid
Maintenance Free
Charging Current 1.1Amps 2.16Amps 2.7Amps 1.1 Amps 2.16 Amps 2.7 Amps
Charging Voltage 41.0Vdc +/-0.5V 82.0Vdc +/-0.5V 82.0Vdc +/-0.5V 41.0Vdc +/-0.5V 82.0Vdc +/-0.5V 82.0Vdc +/-0.5V
Hot – Swappable Yes
Recharge Time 4 hours to 90%
Extended Battery Yes – Hot Swappable (Refer To Run Time Chart)
UniStar ® C 1kVA, 2kVA & 3kVA
UniStar ® C Rack/Tower Universal Design
