18
3
METRIC US
Capacity (dry weight) Ratio [kg/Lit]
1:11 27,6 kg 60.85 lb.
1:10 30,4 kg 67.02 lb.
1:9 33,7 kg 74.30 lb.
Cylinder
Diameter 850 mm 33.46 inch
Depth 537 mm 21.14 inch
Volume 304 Lit 10.74 ft³
Cabinet
Height 1558 mm 61.32 inch
Width 1060 mm 41.73 inch
Depth 1147 mm 45.16 inch
Front loading
Diameter door opening 400 mm 15.75 inch
Height under door 567 mm 22.32 inch
To center 845 mm 33.27 inch
Speed
Wash 10 - 50 tr/min - RPM
Distribution 85 tr/min - RPM
Spin 250 - 1000 tr/min - RPM
G-factor
High spin 475
Dynamic bottom load (N/Hz)
2340/16
Motor (3-phase)
4p. 1470 tr/min 4 kW / 5,36 HP
Drain valve
3"
Water supply
Hard, soft, warm water 3/4"
Steam connection
Steam connection 1/2"
Heating
Electrical 230/400 V 18 kW
Electrical 400V 21 kW - 24 kW
Steam 6 bar
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) mm - inch 1740x1120x1260 mm - 68.50x44.09x49.61inch
Weight
Net 731 kg 1611.58 lb.
Gross 781 kg 1721.81 lb.
Technical data HF304, IHF304, IHF075, CHF304, CHF075
