Alliance Laundry Systems HF150 - Manual (Page 17)

720
[28
.3
5]
126
6 [4
9.82
]
138
6 [5
4.57
]
156 [6.12]
251 [9.88]
346 [13.62]
C D E
35 [1.38]
L
B
A
112
6.
9 [4
4.36
]
105 [4.13]
165
[6.5]
K
116 [4.57]
G I
15
00
[59.
05]
738 [29.05]
900 [35.43] 81 [3.19] 81 [3.19]
15
28
[60.
14]
533 [
20
.9
6]
70 [2.76] 926 [36.46]
900 [35.43]
830 [32.68] 35 [1.38] 35 [1.38]
65 [2.56]
H
240 [9.45]
3
F
H
17
Dimensions HF234, IHF234, IHF055, CHF234, CHF055
Legend: metric mm [inches]
 A. Ventilation soap dispenser
 B. Liquid soap connections
 C. Hard water connections 3/4"
 D. Warm water connections 3/4"
 E. Soft water connections 3/4"
 F. Connection clamps
 G. Electrical connections
 H. Emergency button
 I. Ventilation tub
 K. Drain valve
 L. Steam connections
