Cipher Gun
Cipher Gun
Troubleshooting
Catalyst Problems
1. Catalyst leaking around Needle (inside Needle Housing CPR-2003-02)
· Replace O-Ring (O-S-006) on Needle
· Check for excessive pressure in catalyst system
2. Catalyst leaking around Needle Housing
· Replace O-Ring (O-S-012) on Needle Housing (CPR-2003-02)
3. Catalyst leaking from the Mix Housing / front of the gun
· Check Piston Needle (CPR-2005-01) for wear or damage
· Replace Catalyst Seat (CPR-2012-02) or Catalyst Housing/Seat
(CPR-2012-01)
· Replace O-Ring (O-S-012) under the catalyst seat
· Damaged or Weak Return Spring (04039-1), replace as needed
· Check for excessive pressure in catalyst system
4. Catalyst leaking from around plug on the side of the gun head
· Replace plug Seal (02441-1)
5. No catalyst from the gun
· Make sure trigger is pulling catalyst needle back / open
· Check Catalyst Injector (5104-03-01) for proper operation (drawing 5104-03-01)
· Check gun block for blockages
· Check catalyst pump for proper operation (See catalyst pump manual)
6. Catalyst leaking between fitting and gun block
· Replace O-Ring (O-S-012)
Resin Problems
1. Resin leaking around Needle (inside Needle Housing CPR-2004-01)
· Replace O-Ring (O-S-006) on Needle
2. Resin leaking around Needle Housing
· Replace O-Ring (O-S-012) on Needle Housing (CPR-2004-01)
3. Resin leaking from the Mix Housing / front of the gun
· Check Piston Needle (CPR-2005-01 for wear or damage
· Replace Resin Needle Housing (CPR-2004-01)
· Replace O-Ring (O-S-012) under the resin Needle Housing
· Damaged or Weak Return Spring (04039-1), replace as needed
· Check for excessive pressure in resin system
Chapter
4
