Cipher Gun
MAGNUM VENUS PRODUCTS
Flush Valve Assy 5104-01-01
D5104-01-01 Rev. A - 11/05/01
ITEM PART # DESCRIPTION QTY
1 5104-22-1 Flush Valve Neck 1
2 5104-23-1 Flush Seal Body 1
3 5104-26-1 Flush Valve Seal 1
4 5104-24-1 Flush Valve Body 1
5 5104-25-1 Flush Valve Button 1
6 5104-21-1 Flush Valve Split Seal 1
7 9203-2-3 Compression Spring 1
8 7301-13-008 O-Ring 1
*Do not grease this O-Ring*
9 7301-3-007 O-Ring 1
Flush Valve Assy (5104-03-01)
PARTS LIST
REV. A = ITEM 8, 7301-13-008 WAS 7301-11-008, ADDED *DO NOT GREASE THIS O-RING* NOTE
ITEM PART # DESCRIPTION QTY
10 7304-3-1 Nylon Seal 2
11 7701-6-1 Elbow Fitting 1
12 7701-6-3 Barb Fitting 1
13 7701-2-1 Hose Clamp 1
OPTIONAL PARTS AND ASSEMBLIES
8B 7301-11-008 O-Ring 1
15 5104-02-01 Flush Elbow Assy 1
